NATURAL GAS PROCESS EQUIPMENT TECHNICIAN-DRIVEN TOOLS.
Caddy Controls

NATURAL GAS PROCESS EQUIPMENT

Technician-driven.
Field-informed.

Engineering tools built on real-world experience.
Not just textbook calculations.

From heater and regulator sizing to burner fuel trains, odorant supply, and field-service documentation, Caddy Controls brings hands-on equipment experience to the engineering workflow.

Explore engineering tools
BUILT IN THE FIELD.READY FOR YOURS.
FIELD EXPERIENCE IS THE STARTING POINT.ENGINEERING BRINGS IT TOGETHER.EXPLORE BELOW ↓

01 / NATURAL GAS PROCESS EQUIPMENT

Engineering Tools

Built around the equipment you work on.
Shaped by the conditions you work in.

FIELD SERVICEAVAILABLE IN THE APP STORE ON iOS SOON
Press play to watch Field Wizard in action.

Field Wizard

Turn on-site observations, natural gas equipment details, and photos into organized field-service documentation.

About Field Wizard
A mobile field-service workstream for project-specific data capture and findings reports. Its hosted version has not yet been connected to this website.
NATURAL GAS HEATING02
Caddy Controls Heater Wizard: field-informed heater sizing

Heater Wizard

Size a natural gas line heater for your application in seconds. Enter your flow, pressure, and temperature requirements to generate sizing results instantly, then submit your configuration for a quote. We’ll review your request and email your quote promptly.

PRELIMINARY SIZING · REVIEW REQUIRED

Open Heater Wizard
About Heater Wizard
Live thermal and hydraulic sizing, preliminary specifications, and RFQ PDF export. Specify the BMS in Fuel Train Wizard and request one combined package quote. Send your specification with contact and site details for a reviewed quote. Final sizing and equipment selections require application-specific review before procurement or construction.
BURNER SYSTEMS03
Caddy Controls Fuel Train Wizard: pressure, flow, and component sizing

Fuel Train Wizard

Build the fuel train for your natural-draft heater and pair it with a Burner Management System suited to your application. Generate a P&ID and bill of materials instantly, then submit your configuration for a quote. We’ll review your request and email your quote promptly.

PRELIMINARY SIZING · REVIEW REQUIRED

Open Fuel Train Wizard ↗
About Fuel Train Wizard
A fuel-train design workstream with sizing and bill-of-materials outputs. Component selections, Burner Management System suitability, and relief-installation requirements need independent confirmation before procurement or construction. Open directly for a fuel-train quote, or continue from Heater Wizard to include both specifications in one request.
Caddy Controls Regulator/Relief Sizing Calculator badge, with a technician and illustrative pressure-regulation equipment

04 / PRESSURE REGULATION & RELIEF

Regulator/Relief Sizing Calculator

PRELIMINARY SIZING · REVIEW REQUIRED

Open Sizing Calculator ↗

Size regulators and relief devices for your natural gas application in seconds. Enter your operating pressures and flow requirements to generate sizing results instantly, then submit your selections for a quote. We’ll review your request and email your quote promptly.

About the sizing calculator
Compare Fisher 627 / 627R series, BelGAS 627 series, Dresser ROOTS, Mooney and Flexflo regulators against each manufacturer’s published capacity tables, with Mooney pilots and accessories. Size the downstream Mercer or Taylor relief valve for a wide-open regulator failure, check 627R / R627 internal relief, or size a relief valve on its own. Request a quote for a specific result with its sizing inputs and review notes included. Final selections require confirmation against current manufacturer data, application requirements, and relief-installation requirements. Relief mode is not a complete overpressure-protection design. Badge equipment is illustrative, not a specific manufacturer model.
Caddy Controls Odorant Supply Calculator badge, with a technician at a natural gas odorization skid and odorant storage tank

05 / ODORIZATION

Odorant Supply Calculator

USAGE ESTIMATE · ODORANT RFQ

Open Supply Calculator ↗

Estimate odorant usage, days of supply, and your reorder date from station flow and injection rate. Check NJEX pump capacity at peak flow, then order odorant: your calculator results are included in the quote request automatically. We’ll review your request and email your quote promptly.

About the supply calculator
Covers Arkema Spotleak blends and THT with YZ Systems NJEX odorizers, max/average/low flow cases, a new-steel-pipe fade factor, an annual estimate, and the top-off quantity to reach the maximum fill level. Densities are estimated from component specific gravities; use the SDS or lot value when available. The calculator sets a starting injection rate and supply estimate only. It does not confirm odorization compliance; verify odorant levels in the field.
Caddy Controls Odorant Use Calculator badge, with a technician reading an odorizer stroke counter

06 / ODORIZATION

Odorant Use from Pump Strokes

FIELD ESTIMATE

Open Stroke Calculator ↗

Enter the stroke count from your YZ odorizer display to estimate gallons and pounds of odorant used, with per-day, monthly, and yearly projections, tank use, and pump utilization.

About the stroke calculator
Volume is strokes × cc per stroke (NJEX 6300 = 0.1 cc, 7300 = 1.0 cc, 8300 = 6.0 cc). Output per stroke can drift with line pressure, check valves, and pump wear, so confirm against the tank level drop. For dual-pump units, add the stroke counts from both pumps.
Caddy Controls Meter Set / Service Line Wizard badge, with a technician and a gas meter-set skid

07 / GAS PIPING

Meter Set / Service Line Wizard

PRELIMINARY SIZING · REVIEW REQUIRED

Open Meter Set Wizard ↗

Work back from your load to the main: total the equipment load, size building piping, pick a meter and Dresser regulator family, then size the service line in steel or PE and check the excess flow valve. Request a quote for the meter, regulator, ERT and EFV with your sizing included.

About the meter set / service line wizard
Natural gas or propane vapor. Building piping uses the IFGC 402.4 equations with actual pipe inside diameters; service lines use the IGT Distribution or Mueller equation with a velocity check. Meter, regulator and EFV data come from manufacturer literature (Dresser ROOTS, Elster American, Itron, UMAC/GasBreaker, Elster Perfection). Results are preliminary: final design must follow NFPA 54 / IFGC, 49 CFR Part 192, NFPA 58 and the serving utility's standards.

Engineering tools support your workflow. Outputs require qualified review against application requirements, manufacturer data, and applicable codes. Caddy Controls has no business relationship with the manufacturers listed in these tools. These tools are not a substitute for a qualified engineer. RFQs are sent to regional reps for review and quoting. Want a product line added to the calculators? Reach out.

1. Request details2. Review & send
Your contact information

All contact fields and service details are required. Photos are optional.

What service do you need?
Site & equipment photos Optional

Add up to 8 photos total. JPG, PNG, or WebP, up to 20 MB each before resizing. Photos are optimized for email and location metadata is removed. For HEIC photos, export as JPG first.

Check that nameplate text is readable. Only upload photos you’re authorized to share.

Submitted information goes to Caddy Controls for quoting. Photos are included with your request. Do not include passwords or sensitive security information.

THE CADDY CONTROLS APPROACH

The calculation matters.
So does the experience.

TECHNICIAN-DRIVEN. BY DESIGN.

A calculation is only part of the job. Understanding how natural gas process equipment is installed, operated, serviced, and repaired brings the application into focus.

Caddy Controls tools are shaped by real-world technician experience, not just textbook calculations. That experience informs the questions we ask, the inputs we capture, and the way we organize the work.

Practical experience and sound engineering belong together. Caddy Controls is bringing the two together for our customers in order to be a partner you can rely on.
